CABLE MANAGEMENT

HORIZONTAL-MOUNT
Brush Strip Panels: 16-ga. steel panel with tray and brush strip allows cable bundles to be routed between CBP-2
bristles, keeping dust and contaminants at bay while giving an assist to thermal management. Black finish.
Model No. Description Depth Width
CBP-1 1U brush panel 3.00" 19.00"
CBP-2 2U brush Panel 3.00" 19.00"
Stackable Bars: 14-ga. steel slotted bars can be used independently or stacked on a horizontal plane to save
rack space. A straight bar can be mounted at a right angle to another straight bar for dual-lacing configuration. CMBS
Bars also serve as support bracing for equipment when used with mid or rear rails. Black finish. CMBS-2
Model No. Description Offset Width
CMBS Straight bar --- 19.00" CMBS-4
CMBS-2 Offset bar 2.00" 19.00"
CMBS-4 Offset bar 4.00" 19.00" CMBS-6
CMBS-6 Offset bar 6.00" 19.00" CMBS Series shown stacked. Sizes sold separately.
Stackable Flat Wire: 11-ga. steel flat wire with smooth rounded edges can be used independently or stacked on STACKABLE
a horizontal plane to save rack space while separating cables. Features multiple tiedown slots and holes. Robust CMFW
design can be used as support bracing for equipment when used with mid or rear rails. Black finish.
CMFW-2
Model No. Description Offset Width
CMFW Straight flat wire --- 19.00"
CMFW-2 Offset flat wire 1.75" 19.00" CMFW-4
CMFW-4 Offset flat wire 4.00" 19.00" CMFW Series shown stacked. Sizes sold separately.
Steel Rods: Cable management steel rod with 0.25" diameter. Black finish.
CMR
Model No. Description Offset Width
CMR Straight rod --- 19.00" CMR4
CMR2 Offset rod 1.50" 19.00"
CMR4 Offset rod 4.00" 19.00"
Flex-Clip Panels: 16-ga. steel panel with plastic flex-clips that rotate individually for horizontal or vertical cable CMR2
management. Optional steel D-rings on ends for open frame data racks extend beyond rack width for vertical
routing. Black finish.
Model No. Description D-rings on Ends Width CMC-1HV
CMC-1HV 1U panel, flex-clips --- 19.00"
CMCD-1HV 1U panel, flex-clips 2 19.00"+
D-Ring Panels: 16-ga. steel panel with D-rings welded along center and optional D-rings on ends for open frame
data racks to route cables vertically (end D-rings extend beyond rack width). For localized cable routing, a single CMCD-1HV
D-ring on a 2U bracket punched on E.I.A. spacing is also available. Black finish.
Model No. Description D-rings on Ends Width
CMD-1H 1U panel, D-rings --- 19.00" CMD-2H
CMD-1HV 1U panel, D-rings 2 19.00"+
CMD-2H 2U panel, D-rings --- 19.00"
CMD-2HV 2U panel, D-rings 2 19.00"+
CMD-2V 2U D-ring on bracket --- 0.875"

Slotted Panels: 16-ga. steel panel with flange and slots for cable lacing. Black finish.
CMD-2HV
Model No. Description Width
CMPS-1 1U slotted panel 19.00"
CMPS-2 2U slotted panel 19.00"
CMD-2V
Telescoping Panels: 18-ga. steel panel with flange extends to mount front-to-back within a rack, providing a CMPS-2
versatile solution for wire and cable management. Black finish.
Model No. Description Extension
CMHT1-1730 1U telescoping panel 17.00" - 30.00"
CMHT2-1936 2U telescoping panel 19.00" - 36.00"

CMHT2-1936

Visit www.lowellmfg.com for models and more information. Telescoping panel – extends front-to-back of rack or cabinet 12
