Page 13 - RACKS-PWR-ACC-2021

KSB18 + KSE2X
(sold separately)
Knockdown Shelf: Base and sides sold separately for mix-and-match versatility. 16-ga. steel base with vents
ships with hardware. Black finish.
Model No. Description Depth Quantity Load Capacity For KSB Base
KSE2 2U sides 14.00" 1pr 50 lbs. KSB14 & KSB18 VDS-2-2032 Adjustable depth
KSE3 3U sides 14.00" 1pr 70 lbs. KSB14 & KSB18
KSE4 4U sides 14.00" 1pr 70 lbs. KSB14 & KSB18
KSE2X 2U sides 18.00" 1pr 50 lbs. KSB18 & KSB21
KSE3X 3U sides 18.00" 1pr 70 lbs. KSB18 & KSB21
KSE4X 4U sides 18.00" 1pr 70 lbs. KSB18 & KSB21
KSB14 Vented base 14.00" 1 ea. --- ---
KSB18 Vented base 18.00" 1 ea. --- ---
KSB21 Vented base 21.00" 1 ea. --- --- VDS-1-1525
OPTIONS Adjustable depth
KSTB Clamping bracket
Variable Depth Shelves: 16-ga. steel shelf with vents, adjustable depth and brackets. Black finish. Two styles.
Model No. Height Useable Depth Width Load Capacity
VDS-2-2032 2U 20.00" - 32.00" 19.00" 250 lbs.
VDS-1-1525 1.50" (-1U) 15.25" - 25.00" 19.00" 400 lbs.

Variable Width Shelf: 16-ga. steel, 3-piece shelf with side supports expands from 17.5"-22"W behind front VWS-214
rack rails. Side supports can be installed with long or short side up to emulate 2U or 3U panel space. Black finish.
Model No. Height Depth Useable Width Load Capacity
VWS-214 2U or 3U 14.00" 17.50" - 22.00" 50 lbs.
VWS-218 2U or 3U 18.00" 17.50" - 22.00" 50 lbs.
3U
Keyboard/Monitor Shelf: Reinforced shelf for a monitor and slide-out shelf for keyboard (not included), rotating Adjustable width 2U
tray. Extension tray for mouse for right- or left-hand use. Hinged front panel. Mounts on front and rear rack rails.
Rear rail extension 6". Black finish. Includes wrist pad.
Model No. Height Depth Width Load Capacity Slide-out shelf
KDMS 4.34" 20.00" 19.00" 70 lbs.
KDMS
Sliding Latching Shelf: 16-ga. steel slide-out shelf extends 14.63" and can latch in closed or open position. (equipment not included)
Measures slightly more than 1U. Black finish.
Model No. Height Depth Width Load Capacity
SLS 2.50" 14.63" 19.00" 50 lbs.
Fixed Writing Surface: 16-ga. steel frame with woodgrain laminate finish. Mounts facing out from rack. Slide-out shelf
Model No. Height Surface Depth Width Load Capacity
FWS-215 2U 15.00" 19.00" 30 lbs.
SLS
RMK Shelf: 14-ga. steel shelf used with non-rackmount equipment up to 17.38"W. Sides fold down for flat
shipping and storage. Optional top clamp. Black finish.
Model No. Height Depth Width Load Capacity FWS-215
RMK214-LFP 2U 14.00" 19.00" 50 lbs.
RMK314-LFP 3U 14.00" 19.00" 50 lbs.
RMK218-LFP 2U 18.00" 19.00" 50 lbs.
RMK318-LFP 3U 18.00" 19.00" 50 lbs.
OPTIONS
RMK-TCMP Top clamp

Sides fold down on hinges
Center-Mount Shelf: Designed for 2-post racks, this 16-ga. steel shelf provides versatile solution for non- (no assembly required)
rackmount equipment. Black finish.
Model No. Height Drawer Depth Width Load Capacity
CMS-220 2U 20.00" 19.00" 50 lbs. RMK314-LFP
CMS-324 3U 24.00" 19.00" 50 lbs.

CMS-220

Visit www.lowellmfg.com for models and more information. 10
