RACK BASES

MOBILE BASES
LMB Series: Base mounts inside rack frame creating a platform flush with bottom rack space—ideal for heavy
equipment mounted in lowest rack position. Includes 3.00" swivel casters and hardware. Model numbers ending
with “F” have special casters made to protect fine floors like wood, marble or tile. For rack series: LER, LFR, LGR.
Model No. Depth Width Height Material Increases Rack Height Total Load Capacity
LMB-27 26.75" 22.81" 3.00" 14-Gauge Steel 1.25" 1400 lbs. LMB-27F
LMB-32 31.75" 22.81" 3.00" 14-Gauge Steel 1.25" 1400 lbs.
LMB-36 35.75" 22.81" 3.00" 14-Gauge Steel 1.25" 1400 lbs.
LMB-42 41.75" 22.81" 3.00" 14-Gauge Steel 1.25" 1400 lbs.
LMB-27F 26.75" 22.81" 3.00" 14-Gauge Steel 1.50" 800 lbs.
LMB-32F 31.75" 22.81" 3.00" 14-Gauge Steel 1.50" 800 lbs.
LMB-36F 35.75" 22.81" 3.00" 14-Gauge Steel 1.50" 800 lbs.
LMNB Series: Base mounts inside rack frame creating a platform flush with bottom rack space—ideal for heavy LMNB-32
equipment mounted in lowest rack position. Includes 3.00" swivel casters and hardware. For rack series: LGNR,
LGVR.
Model No. Depth Width Height Material Increases Rack Height Total Load Capacity
LMNB-27 26.75" 21.75" 3.00" 14-Gauge Steel 1.25" 1400 lbs.
LMNB-32 31.75" 21.75" 3.00" 14-Gauge Steel 1.25" 1400 lbs.
LMNB-36 35.75" 21.75" 3.00" 14-Gauge Steel 1.25" 1400 lbs.
LMSB Series: Base mounts under rack frame. Casters are set to the perimeter to enhance stability of a loaded
rack. Includes 3.00" swivel casters (two locking, two non-locking). Model ending with “FL” has special casters
made to protect fine floors like wood, marble or tile. For rack series: LER, LFR, LGR (with 22” depth).
Model No. Depth Width Height Material Increases Rack Height Total Load Capacity
LMSB-22 21.88" 22.31" 4.06" 14-Gauge Steel 4.06" 1400 lbs. LMSB-22
LMSB-22FL 21.88" 22.31" 4.33" 14-Gauge Steel 4.33" 800 lbs.
LXR-MB Series: Skirted base mounts under rack frame. Includes 3.00" non-locking swivel casters. Models
ending with “F” have special casters made to protect fine floors like wood, marble or tile. For slim rack series: LXR-MB26
LXR and LVR (with 21" or 26.25" depth setting).
Model No. Depth Width Height Material Increases Rack Height Total Load Capacity
LXR-MB21 19.00" 21.00" 3.95" 16-Gauge Steel 3.95" 500 lbs.
LXR-MB26 19.00" 26.00" 4.06" 16-Gauge Steel 4.06" 620 lbs.
LXR-MB21F 19.00" 21.00" 3.95" 16-Gauge Steel 3.95" 500 lbs.
LXR-MB26F 19.00" 26.00" 4.06" 16-Gauge Steel 4.06" 620 lbs.
STATIONARY BASES
LSB Series: Base mounts inside rack frame creating a platform flush with bottom rack space—ideal for heavy
equipment mounted in lowest rack position. Does not increase rack height. For rack series: LER, LFR, LGR.
Model No. Depth Width Height Material
LSB-22 20.38" 22.81" 3.00" 16-Gauge Steel
LSB-27 26.75" 22.81" 3.00" 16-Gauge Steel
LSB-32 31.75" 22.81" 3.00" 16-Gauge Steel LSB-27
LSB-36 35.75" 22.81" 3.00" 16-Gauge Steel
LSB-42 41.75” 22.81" 3.00" 16-Gauge Steel
LSSB Series: Shallow base mounts inside rack frame creating a sub-floor 2.25" below bottom rack space— LSSB-22
ideal to mount accessory devices on floor of installation. Does not increase rack height. For rack series: LER, LFR,
LGR (with 22" or 27" depth).
Model No. Depth Width Height Material
LSSB-22 20.38" 22.81" 0.75" 16-Gauge Steel
LSSB-27 26.75" 22.81” 0.75" 16-Gauge Steel
