POWER STRIPS Rackmount power strips include either universal brackets or clips and wire ties to mount vertically inside
DISTRIBUTED POWER FEATURES 15A or 20A (rating is per circuit)
equipment racks. Shelf-mount power strips include screws to mount to rear flanges in Lowell US Series shelves.
Power products for special applications, including half rack panels and modular power strips,
NLINE
can be found online at www.lowellmfg.com.
• Power Rating:
• Power Input:
6 ft. or 12 ft. standard cord, 6 ft. detachable cord, 6 ft. flexible conduit (non-
metallic) with pigtail leads, or pigtail leads at both ends of chassis.
• Switch:
rocker switch. Models without a switch provide continual power to "unswitched"
outlets (as long as power is supplied to the unit itself).
NEMA 5-15R, NEMA 5-20R, or NEMA 5-20R IG (Insulated Ground)
• Outlets: Power strips with an on/off switch activate and deactivate "switched" outlets via a
• Circuits: Corded power strips are available with one circuit. Hardwired power strips are
available with single or multiple (1-10) circuits.
• Surge Protection: Some power strips include built-in surge protection, as indicated in the chart
below. Power strips with one star () protect against surges up to 6,500A; those
with two stars () protect against surges up to 40,000A.
Advanced Surge Suppression against power surges up to 72,000A can be
added as a separate unit; see page 33.
• Remote Power Power strips with RPC circuitry must be connected to a device (such as a
ACS-1512 Control (RPC): sequencer or SPST switch) that can activate the power strip from a remote
ACS-2020-IG-10C-HW • Origin: through connections (pg. 32).
location. ACS-2018-5C-RPCP-HW power strip for use with remote control pass-
Most power strips are assembled in the U.S.A. with a U.S. steel chassis and global
components. Imported power strips are sourced globally. See the chart below or
individual spec sheets.
You can also design your own power strip placing 15A,
20A, or 30A power modules right where you need them.
MODEL SUMMARY Visit www.lowellmfg.com
Circuits
NEMA NEMA
Power Outlets Outlets Surge Mtg.
Model No. Qty. Rating 5-15R 5-20R Chassis Power Input Protection Misc. Activation Hardware NRTL Origin
ACS-1505-SW 1 15A 5sw --- 12" 6' Det. Cord --- --- Rocker Brackets ETL USA
ACS-1505-SW-SD 1 15A 5sw --- 12" 6' Det. Cord --- Rocker Brackets ETL USA
ACS-1506 1 15A 6un --- 20" 6' Cord --- --- Clips/Ties UL Imported
ACS-1506-WW 1 15A 6un --- 12" 6' Cord --- --- --- Screws ** ETL USA
ACS-1507 1 15A 7un --- 12" 6' Det. Cord --- --- --- Screws ** ETL USA
ACS-1510-RPC 1 15A 8sw + 2un --- 30" 6' Det. Cord --- RPC External * Brackets ETL USA
ACS-1512 1 15A 12un --- 32" 12' Cord --- --- Clips/Ties UL Imported
ACS-1524 1 15A 24un --- 60" 12' Cord --- --- Clips/Ties UL Imported
ACS-1524-2C 2 15A 24un --- 70" Pigtails (ends) --- --- --- Clips/Ties ETL Imported
ACS-2012 1 20A 8un 4un 32" 12' Cord --- --- Clips/Ties UL Imported
ACS-2010-RPC-HW 1 20A --- 8sw + 2 un 30" 6' Flex-Conduit --- RPC External * Brackets ETL USA
ACS-2014-HW 1 20A --- 14un 30" 6' Flex-Conduit --- --- --- Brackets ETL USA
ACS-2014-2C-HW 2 20A 8un 6un 30" 6' Flex-Conduit --- --- --- Brackets ETL USA
ACS-2018-5C-RPC-HW 5 20A --- 16sw + 2un 60" 6' Flex-Conduit --- RPC External * Brackets ETL USA
ACS-2018-5C-RPCP-HW 5 20A --- 16sw + 2un 60” 6’ Flex-Conduit RPC SEQ-P4 or SEQR-P4 * Brackets ETL USA
ACS-2020-6C-HW 6 20A --- 20un 60" 6' Flex-Conduit --- --- --- Brackets ETL USA
ACS-2020-IG-6C-HW 6 20A --- 20un (IG) 60" 6' Flex-Conduit --- --- --- Brackets ETL USA
ACS-2020-IG-10C-HW 10 20A --- 20un (IG) 60" 6' Flex-Conduit --- --- --- Brackets ETL USA
ACS-2024 1 20A 16un 8un 70" 12' Cord --- --- Clips/Ties UL Imported
ACS-2024-2C 2 20A --- 24un 70" Pigtails (ends) --- --- --- Clips/Ties ETL Imported
* Items are required but not included. Order external activation switches separately (see pg. 30). ** Screws are included to mount the power strip to rear notches in Lowell US Series rack shelves.
