Slotted Holes: Aluminum or steel rackmount panel w/slotted hole vent pattern and formed flange. AVPB
Model No. Height Width Material Finish
AVPB-1 1U 19.00" 0.050" Aluminum Brushed Black Anodized
AVPB-2 2U 19.00" 0.050" Aluminum Brushed Black Anodized
SVSP-1* 1U 19.00" 18-Gauge Steel Black Semi-Gloss
SVSP-2* 2U 19.00" 18-Gauge Steel Black Semi-Gloss
SVSPH-1 1U 10.40" 18-Gauge Steel Black Semi-Gloss
SVSPH-2 2U 10.40" 18-Gauge Steel Black Semi-Gloss SVSP
* Available in multi-pack carton. See spec sheet for details. NOTE: 3U, 4U and 7U SVSP panels available under "Specialty Tops".
PUNCHED PANELS
Decorator Style Punches: Steel panel with flange is punched for decorator style devices. Includes hardware.
Some panels include a label pocket (templates found online). Black semi-gloss finish.
Model No. Height Width Punches Label Area Device Mount Material
D3P-ID-1 1U 19.00" 3 Yes Horizontal 16-Gauge Steel
D3P-ID-2 2U 19.00" 3 Yes Horizontal 16-Gauge Steel DBB
D4P-1 1U 19.00" 4 --- Horizontal 18-Gauge Steel
D8P-ID-3 3U 19.00" 8 Yes Vertical 18-Gauge Steel
D9P-ID-3 * 3U 19.00" 9 Yes Vertical 18-Gauge Steel D3P-ID-2
OPTIONS
DBB-4 Blank filler plates for unused decorator style positions (4 pack)
DBB-50 Blank filler plates for unused decorator style positions (50 pack)
DBB-100 Blank filler plates for unused decorator style positions (100 pack) D4P-1
* Panel can be used for up to four multi-gang devices mounted on alternate spacing. Confirm clearance for non-Lowell controls.

Neutrik Punches: Steel panel with flange punched for Neutrik-D or Switchcraft-E connectors includes black D8P-ID-3
®
and nickel-plated screws and label pocket. Black semi-gloss finish.
Model No. Height Width Punches Label Area Material
N10P-ID-1 1U 19.00" 10 Yes 20-Gauge Steel
Wall Plate Punches: Steel panel punched for devices that have a 1-gang standard, non-removable wall plate
that installs with two screws. Black semi-gloss finish. Spacing is not suitable for 2-gang devices. D9P-ID-3
Model No. Height Width Punches Device Mount Material
SG6P-3 3U 19.00" 6 Vertical 16-Gauge Steel
VC Punches: Steel panel punched for volume controls such as Lowell LVC Series. Includes plugs for unused positions
and label pocket. Does not include device-mounting hardware. NOTE: Preloaded option available. See spec sheet.
Model No. Height Width Punches Label Area Material N10P-ID-1
LVC8P-ID-2 2U 19.00" 8 Yes 18-Gauge Steel

SPECIALTY PANELS SG6P-3
Two Handle Panel: Steel rackmount panel with chrome handles can be mounted in the lower third of a mobile
or pull-out rack to improve maneuverability. Black semi-gloss finish.
Model No. Height Width Handle Depth Material
SPH-1 1U 19.00" 1.1875" 14-Gauge Steel
Knockout Panel: Pair of steel knockout panels punched for Neutrik D-series panel connectors. For use in rack Label LVC8P-ID-2
®
series: LER, LGR, LPR, LPPR, and LWR. Black wrinkle finish.
Model No. Width (Each) Overall Height Material
KOP-N 9.69" 2.69" 16-Gauge Steel
Knockout Panel w/Accessories: 10"W panel with fans, LED lights, or power outlets replaces rear KO panel in IP-ID-1
most racks (see spec sheet). Black semi-gloss finish.
Model No. Description
KOP-L-SW Steel panel w/two LED lights and button switch SPH-1
KOP-L-PSW Steel panel w/two LED lights and proximity (auto on/off) switch
KOP-L* Add-on unit (steel panel w/two LED lights, no switch) *
KOP-B Steel panel w/dual blower fans and power supply
KOP-BT Steel panel w/dual blower fans, power supply, and thermostat probe KOP-AC1502
KOP-AC1502 Steel panel w/two 15A outlets and 6-ft. cord with entry ports
* Only works with KOP-L-SW or KOP-L-PSW KOP-N
ID Panel: Steel panel has label pocket to identify equipment mounted above and below it. Black semi-gloss finish.
Model No. Height Width Label Area Material
IP-ID-1 1U 19.00" Yes 18-Gauge Steel

Visit www.lowellmfg.com for models and more information. 22
