NETWORKING

SR Series swing gate wall rack SGR Series heavy duty swing gate
Mounting Rails fixed, tapped 10-32 wall rack
Rack Units 12, 20 or 25U Mounting Rails fixed, tapped 10-32
Overall Depth 12, 18 or 24 in. Rack Units 12 or 20U
Overall Width 19.60 in. Overall Depth 13.21 or 19 in.
Load Capacity 100 lbs. Overall Width 20.03 in.
Ships unassembled Load Capacity 150 lbs.

SWINGS OPEN 90°: Front gate (left or right orientation) swings
SWINGS OPEN 90°: Front gate (left or right orientation) open from fully open side for extraordinary access.
swings open for access.

PFR Series pivot frame wall rack HUB Series hinged wall bracket
Top Cover optional Top Cover optional
Front Panel optional Mounting Rails fixed, tapped 10-32
Mounting Rails fixed, tapped 10-32 Rack Units 2, 4 or 6U
Rack Units 4, 6 or 8U Overall Depth 6 in.
PIVOTS DOWN: Overall Depth 6, 12 or 18 in. Overall Width 19.17 in.
Frame pivots Overall Width 19.30 in.
down 90° with Load Capacity 30-60 lbs. 180° SWING-OUT: Hinged design
absolute stop allows easy access to cables.

RCC Series remote consolidation cabinet RCCD Series remote consolidation cabinet
Style surface with flip-top access
Front Door included (vented) Style surface
Mounting Rails fixed, dual-punch* Front Door included (flip-top, vented)
Top Rack Units 2U horiz., pivot-down access Mounting Rails fixed, dual-punch*
Bottom Rack Units 2 or 4U vertical-mount Top Rack Units 4U horiz., pivot-down access
Overall Depth 5.00 - 7.50 in. Bottom Rack Units 6U vertical-mount
Overall Width 25.50 in. Overall Depth 11.19 in.
Load Capacity 150 lbs. Overall Width 25.50 in.
* Tapped 10-32 for screws, plus holes for alternate hardware Load Capacity 150 lbs.
* Tapped 10-32 for screws, plus holes for alternate hardware

FRONT DOOR INCLUDED: Vented steel with beveled
edges and side lock. FRONT DOOR INCLUDED: Vented steel with beveled
edges, side lock and flip-top.

SMR Series side/top-mount wall rack WXR Series slim wall rack
Style surface Mounting Rails fixed, tapped 10-32
Versatile Mount side- or top-mount Rack Units 8, 12, 22 or 30
Mounting Rails adjustable, tapped 10-32 Overall Depth 6, 12 or 18 in.
Rack Units 2 or 4U Overall Width 19.21 in.
Overall Depth 21.63 in. Load Capacity 125 - 200 lbs.
Overall Width 19.13 in. Ships unassembled
Load Capacity 50 lbs.

VERTICAL OR HORIZONTAL MOUNT: Bi-directional keyhole slots
on standard 16 in. centers mounts rack vertically or horizontally.

Visit www.lowellmfg.com for models and more information. 4
