WALL RACKS

One rack unit (U) equals 1.75 inches.
RACKS & BOXES STATIONARY LWER Series stationary wall rack VR Series wall rack (space saver)

Rack Units
2, 3, or 4U
Side Panels
welded
Overall Height
Front Door
6 in.
included (solid)
Mounting Rails
3.94, 5.69 or 7.44 in.
fixed, tapped 10-32
Overall Depth
Rack Units
200 lbs.
Load Capacity
Overall Depth
18.18 in.
23.06 in.
Overall Width
Load Capacity 7 or 10U Overall Width 19.17 in.
150 lbs. (UL Listed)
FRONT DOOR INCLUDED:
Made in USA 100% Certified U.S. Steel Solid steel with keyed lock.
SWING-OPEN
Economical
LWSR Series swing-open, wall rack LWR Series heavy duty sectional,
Side Panels welded swing-open wall rack
Front Door optional Side Panels welded
Mounting Rails fixed, tapped 10-32 Front Door optional
Rack Units 7, 10, 12 or 16U Mounting Rails adjustable, tapped 10-32
Overall Depth 22 in. Rack Units 7, 10, 12, 16, 21, 24 or 35U
Overall Width 23.06 in. Overall Depth 19, 23, 28 or 32 in.
Load Capacity 150 lbs. Overall Width 23.06 in.
SWINGS OPEN 90°:
Cabinet swings open for Load Capacity 125-300 lbs. (UL Listed)
access to equipment.
SWINGS OPEN GREATER
THAN 90°: Cabinet swings
open for access to equipment.

LWBR Series swing-open wall rack
with support base
Side Panels welded
Front Door optional
Mounting Rails adjustable, tapped 10-32
Rack Units 24, 35, 40 or 44U
Overall Depth 22.40, 28.40 or 32.40 in.
Overall Width 23.06 in.
Load Capacity 500 lbs.

SWINGS OPEN ON BASE: Cabinet swings open
90° on support base for access to equipment.

TILT-OUT

LTR Series tilt-out wall rack LTCR Series tilt-out wall rack
Style surface or recessed with dampers
Main Compartment manual release Style surface or recessed
Mounting Rails adj. & fixed, tapped 10-32 Main Compartment controlled release
Rack Units 3U horiz.; 2, 3 or 4U vertical Mounting Rails adj. & fixed, tapped 10-32
Overall Depth 5.13 - 8.13 in. Rack Units 3U horiz.; 3U vertical
Overall Width 24.50 - 25.70 in. Overall Depth 6.09 or 6.80 in.
Load Capacity 100 lbs. Overall Width 25.00 or 26.50 in.
Load Capacity 50 lbs.
DIN RAIL: Found in
MANUAL RELEASE: base of LTR Series
Main compartment wall racks. CONTROLLED RELEASE:
tilts out for equipment Main compartment
operation, and down features dampers for
for servicing. controlled descent.
