STAND-ALONE

LER Series enclosed rack LSER Series seismic-certified, enclosed
Side Panels welded Side Panels welded
Rear Door included* Rear Door included
Front Door optional Front Door optional
Mounting Rails adjustable, tapped 10-32 Mounting Rails adjustable, tapped 10-32
Rack Units 18, 21, 24, 35, 40 or 44U Rack Units 35, 40 or 44U
Overall Depth 22, 27 or 32 in. Overall Depth 27 or 32 in.
Overall Width 23.06 in. Overall Width 23.06 in.
Load Capacity 500-3150 lbs. (UL Listed) Load Capacity 900-1200 lbs.* (seismic-cert)
* may be omitted if not needed 3150 lbs. (UL Listed)
* Professional Engineer certified for two categories of seismic
qualification. See online P.E. Certification documents for details.
RACK WITH BUNDLED ACCESSORIES AVAILABLE:
See page 7.

Economical
LFR Series fixed rail rack LHR Series host rack (exterior cabinet
Side Panels welded with pull-out rack)
Rear Door included Side Panels welded
Front Door optional Rear Access Cover optional
Front Rails fixed, tapped 10-32 Front Door optional
Rear Rails optional (semi-adjustable) Mounting Rails corner-post, tapped 10-32
Rack Units 21, 24, 35, 40 or 44U Rack Units 24, 35 or 44U
Overall Depth 22 or 27 in. Overall Depth 33 or 43 in.
Overall Width 23.06 in. Overall Width 24.00 in.
Load Capacity 500-2000 lbs. (UL Listed) Load Capacity 750 lbs.

REAR SUPPORT BRACKETS: Allow semi-adjustable
mounting of rails and accessories in rear of rack. SLIDES OUT & ROTATES: Interior base and rack slide out of cabinet
allowing rack to rotate, and can disengage from cabinet for shop wiring.

LLR Series laminate rack LDR Series designer rack
Front/Rear Doors ----- Side Panels included
Mounting Rails fixed, tapped 10-32 Rear Access Cover included
Rack Units 10, 12, 16 or 21U Front Door included (tempered glass)
Overall Depth 18 in. Mounting Rails adjustable, tapped 10-32
Overall Width 20.41 in. Rack Units 18, 27, 35 or 42U
Laminate Finish Black Woodgrain Overall Depth 24 in.
Load Capacity 200 lbs. Overall Width 22.31 in.
Ships unassembled Load Capacity 500-1200 lbs.

FRONT DOOR INCLUDED: Smoked grey
tempered glass door with keyed lock.
RACK WITH INSTALLED ACCESSORIES
AVAILABLE, see page 7.

Visit www.lowellmfg.com for models and more information. 2
