ADVANCED SURGE SUPPRESSION 10 WARRANTY

DISTRIBUTED POWER FEATURES:
Lowell’s Advanced Surge Suppression provides multiple layers of protection for equipment on a single circuit. With TCR technology
(Triple Clamping Redundancy), these advanced devices can protect sensitive equipment from harmful power surges and spikes
YEAR
up to 72,000A when fully active.

•
Suppresses line to neutral with no ground contamination
•
Excellent EMI/RMI filtering
Rotating plate allows front or side access to outlets.
•
Detachable (Det. Cord) or attached cord (Cord) and hardwired units (Flex-Conduit)
•
•
ETL Listed. UL1449 third edition compliant. ANSI C62.41 compliant.
•
Choice of over/under protection (VTE, turns outlets off when voltage exceeds specified parameters), or remote power control
• Mounting brackets for versatile installation
(RPC, allows SPD to be controlled by a remote switch–not included).
MODEL SUMMARY
Model No. Power Rating Outlets Power Input Chassis Misc. NRTL Origin
ACSP-1502-VTE 15A (2) NEMA 15A 6' Det. Cord 9" x 1.75" x 6" Over/Under Protection ETL USA
ACSP-1502-RPC 15A (2) NEMA 15A 6' Det. Cord 9" x 1.75" x 6" RPC ETL USA
ACSP-2002-VTE 20A (2) NEMA 20A 6' Cord 9" x 1.75" x 6" Over/Under Protection ETL USA
ACSP-2002-RPC 20A (2) NEMA 20A 6' Cord 9" x 1.75" x 6" RPC ETL USA
ACSP-2002-RPC-HW 20A (2) NEMA 20A 6' Flex-Conduit 9" x 1.75" x 6" RPC ETL USA

MULTI-OUTPUT DC POWER DISTRIBUTION

Designed for continuous operation, the DCP provides power banks, each with eight outputs. This is an ideal format to streamline installations that use DC powered devices.
Power banks are available in various combinations of 5VDC, 12VDC, or 24VDC. Optional 12 in. x 1.625 in. x 6 in. chassis or compact 7 in. x 1.625 in. x 6 in. in. chassis.

FEATURES:

• Power banks are available in various combinations and color-coded for easy identification of the output
voltage (5V=orange, 12V=yellow, 24V=red).
• Each individual output is protected by a PTC fuse (with auto reset) for overload protection, which
enables other outputs to continue functioning even if one shuts off.
• An LED status indicator on each bank indicates power status (active/inactive).
• Utilizes Phoenix style connectors for quick installation.
• Mounting brackets mount the unit to a wall or shelf.
Larger (12 in. units) can also be mounted in a rack.
• Universal input (100-240VAC 50/60Hz)
• C14 power inlet, compatible with international standards.
• ETL Listed. UL60065 compliant.

MODEL SUMMARY

Total Chassis POWER BANK 1 POWER BANK 2
Model No. Power Input NRTL Origin
Watts (W x H X D) Output Voltage Output Qty. Total Amps Color Output Voltage Output Qty. Total Amps Color
DCP-55 110 12 in. x 1.625 in. x 6 in. 6' Det. Cord 5 VDC 8 11A Orange 5 VDC 8 11A Orange ETL USA
DCP-512 247 12 in. x 1.625 in. x 6 in. 6' Det. Cord 5 VDC 8 11A Orange 12 VDC 8 16A Yellow ETL USA
DCP-524 247 12 in. x 1.625 in. x 6 in. 6' Det. Cord 5 VDC 8 11A Orange 24 VDC 8 8A Red ETL USA
DCP-1212 384 12 in. x 1.625 in. x 6 in. 6' Det. Cord 12 VDC 8 16A Yellow 12 VDC 8 16A Yellow ETL USA
DCP-1224 384 12 in. x 1.625 in. x 6 in. 6' Det. Cord 12 VDC 8 16A Yellow 24 VDC 8 8A Red ETL USA
DCP-2424 384 12 in. x 1.625 in. x 6 in. 6' Det. Cord 24 VDC 8 8A Red 24 VDC 8 8A Red ETL USA
DCP-5 55 7 in. x 1.625 in. x 6 in. 6’ Det. Cord 5 VDC 8 11A Orange --- --- --- --- ETL USA
DCP-12 192 7 in. x 1.625 in. x 6 in. 6’ Det. Cord 12 VDC 8 16A Yellow --- --- --- --- ETL USA
DCP-24 192 7 in. x 1.625 in. x 6 in. 6’ Det. Cord 24 VDC 8 8A Red --- --- --- --- ETL USA
