- Configurable top has 12U opening for 19 in. panels
- Open sides, X-frame construction, with multiple openings
- Open front (optional door)
- Rear door with top/bottom vents and keyed lock
- Two-pair fully adjustable rails tapped 10-32 with RU scale
- Cable Management: Multiple lacing points, holes, knockout panels
- Pilot point screws with captive washers
- Grounding stud
- Threaded inserts
- Beveled corners
- Black-textured powder-coat finish
- Includes P.E. Certified documentation
- Rack Space: 44U
- Height: 83.125 in.
- Width: 23.06 in.
- Depth: 27.00 in. (24.34 usable)
- UL load capacity: 3150 lbs.
- Seismic-Certified load capacity: 900-1200 lbs. (see Technical Downloads)
- TAA compliant
- BAA compliant
- EIA/TIA compliant
- UL 2416 Listed
- USA-certified steel
- Made in USA
- P.E. Certified: Seismic Sec. 1613 2009 IBC, 2010 CBC; 2010 OSHPD
The EIA/TIA-compliant, seismic-certified gangable rack shall be Lowell Model No. LSGR-4427 which shall include P.E. Certified documentation as specified in the 2009 International Building Code Section 1613, 2010 California Building Code Section 1613 and 2010 California’s Office of Statewide Health Planning and Development. Overall measurements shall be 83.125″H x 27″D x 23.06″W with panel space of 44 rack units. The rack shall include a recessed rear door with vents and keyed lock; top with 12U opening; open base with grounding stud and holes for anchor bolts (not included); two-pairs adjustable mounting rails with printed RU increments; knockout panels with combination knockouts above and below rear door; and provisions to mount an optional surface-mount front door (ordered separately). The rack shall be manufactured in the USA using USA-certified steel and have a black-textured powder-coat finish. It shall be UL 2416 Listed, Trade Agreement Act (TAA) compliant, and Buy American Act (BAA) compliant.
