- Configurable top has 17U opening for 19 in. panels. Solid closure panels included.
- Open sides with lacing bars for video cable bundles
- Open front (optional door)
- Solid steel rear door with key lock
- Two-pair fully adjustable rails tapped 10-32 (printed RU scale)
- Cable Management: multiple lacing points, holes, knockout panels
- Pilot Point screws with captive washers
- Grounding stud
- Threaded inserts (for optional leg levelers)
- Beveled corners
- Black wrinkle powder epoxy finish
- Rack Space: 44U
- Height: 83.125 in.
- Width: 22.00 in.
- Depth: 36.00 in.
- Useable Depth: 33.34 in.
- Load Capacity: 3150 lbs.
The EIA/TIA compliant, UL Listed (UL2416) 19″ EIA gangable equipment rack shall be Lowell Model No. LGVR-4436 which shall measure 83.125″H x 36″D x 22″W (33.34″ useable depth x 44 rack units). The rack shall be UL Listed in the U.S. and Canada with a load capacity of 3150 lbs. Construction shall be fully welded 16-ga. steel frame with 14-ga. steel top and 14-ga. steel bottom reinforced at load-bearing junctions and finished with a durable black powder epoxy coating. It shall include two pairs of 11-ga. steel adjustable rails with mounting holes tapped 10-32 and rack unit increments printed on EIA spacing. Top shall have integral rails with mounting holes tapped 10-32 to accept 19″W solid panels (included as shipping stiffeners) or optional accessories. Rear frame shall feature knockouts (1/2″, 3/4″, 1″, 1-1/2″) for conduit wiring and BNC knockouts for UHF/VHF antennas. Sides shall feature eight lacing bars. The rack shall include a solid recessed rear door with key lock.
