- Power Rating: 800VA to 3000VA (see spec sheet)
- Receptacles: (8) NEMA 5-15R or 5-15/20R
- Line Cord: 6 ft.
- Chassis: 2U
- Battery: Sealed, lead acid
- Battery Run Times: vary based on condition, age, cycles, ambient temp.
- Output Voltage: 120VAC nominal (110/115/127 selectable)
- Pure sine wave
- Efficient operation: up to 99% (ECO mode); 95% (Buck & Boost mode)
- Hot swappable battery
- Auto restart after full discharge
- Smart LCD display
- Programmable receptacle group
- Temperature compensation
- 4-point rack rail kit (min. 22″D) plus tower pedestals
- 3 year warranty on electronics and battery
The uninterruptible power supply shall be Lowell model ________ (UPS8-800, UPS8-1100, UPS8-1500, UPS8-2000, UPS- 2200, UPS8-3000), which shall feature a four-point rail kit for rack installation, as well as tower pedestals for alternate applications. The 2U chassis shall measure 17.2″ x 3.5″ x _________ (16.1″, 19.9″, 24.6″). The UPS shall operate on 120VAC/60Hz current with nominal output of 120V (110/115/127 selectable). Power rating shall be ___ (800VA, 1100VA, 1500VA, 2000VA, 2200VA, 3000VA). The unit shall feature NEMA receptacles and a 6 ft. power cord with plug. The UPS shall include a battery that is hot-swappable, and has a run time of _____ (half load) or ____ (full load).
- UPS-SNMP: Web/SNMP card for remote monitoring
- UPS-SNMP-EMP: Environmental monitor for use with SNMP card
- UPS-RELAY: Dry contact card
- UPS-XBDM-20RCD: Bypass module allows servicing without interruption of power (for UPS8-2000, -2200)
- UPS-EW Series: 5 year extended warranty. Must purchase simultaneously with UPS.
- UPS-XBP Series: Expansion battery pack for extended run times
