SVP Series, 1U panel with staggered hole vent pattern -- 35% open area

SVP-4CC - DISCONTINUED

Name: SVP-4CC - DISCONTINUED
SKU: SVP4CC
Availability: InStock

SEE ALTERNATIVE: SVP-2CC

$249.20 MSRP

DISCONTINUED | Out of Stock
Recommended Alternative: SVP-2CC

Rack vent panel is steel with a black powder epoxy finish. The panel features small staggered holes for passive ventilation (35 percent open area). Available in single or multi-pack cartons.

Add to Favorites

Compare

Material: 18-gauge steel
Finish: Smooth black semi-gloss
Flange: 0.625 in.
Small Holes: 0.0781 in. diameter on 0.125 in. staggered centers
Open Area: 35 percent
Width: 19 in.
Height: 4U
Multi-carton pack of 6

Spec Sheet: 1061-SVP
CAD drawing: SVP-1

TAA Compliant
EIA/TIA Compliant
Certified U.S. Steel
Made in U.S.A. (BAA)

The rackmount vent panel shall be Lowell Model SVP-4CC, which shall be 18-gauge certified U.S. steel perforated with 0.0781 in. diameter holes on 0.125 in. staggered centers creating 35 percent open area. The panel shall feature a 0.625 inch flange and smooth black semigloss powder epoxy finish. The panel shall measure 19 in. wide x 4U.
