Standalone remote power control, 15A, C13 outlets, pass-through connections

RPC-P15-U: Remote Power Control 15A - Image 3

RPC-P15-U - DISCONTINUED

Name: RPC-P15-U - DISCONTINUED
SKU: RPC-P15-U
Availability: InStock

Out of Stock

$284.00 MSRP

DISCONTINUED | Out of Stock

Use model RPC-P15-U with a compatible sequencer or relay to provide a low voltage way to control AC power to remote equipment. Each device has a DIP switch to set its position in the startup order. Dual RJ45 jacks allow for quick installation. Only the first module in a series needs to connect to a compatible sequencer for activation (order sequencer separately). IEC C13 receptacles.

Product Video

Add to Favorites

Compare

Steel chassis with black finish
Overall Chassis Dimensions: 8.00 in. x 3.25 in. x 1.95 in
Power Rating: 100-250VAC, 15A
Power Inlet: IEC C14. Includes two 6-ft. cords (C13 to NEMA 5-15P, and C13 to C14)
Power Outlets: IEC C13 duplex
RJ45 jacks (2)
DIP Switch: Because the sequence step is selected via the switch on each RPC-P unit, the startup sequence can be quickly modified without re-wiring.
Activation: This model requires sequencer (SEQ-P4) with an external trigger (SPST switch or DSP voltage connection) for activation.
Multiple RPC-P units can be connected to each other (or compatible relays) to control all from a single location (up to 20 RPC-P units per step)

Spec Sheet: 2035-RPCP15U

ETL Listed in U.S./Canada (UL60065)
Certified U.S. Steel
Assembled in U.S.A. with global components

The device for remotely controlling AC power shall be Lowell model RPC-P15-U, which shall be a 8.00″L x 3.25″W x 1.95″ steel chassis with black powder epoxy finish. The remote power control shall feature RJ45 jacks and C13 duplex power outlet. Power rating shall be 100-250VAC. Power input shall be via 6 ft. cord.

RPS Series: SPST switches (maintained and momentary)
SEQ-P4: Low-voltage sequencer
RY-P Series: DPDT relays
