DCP-5: Power Supply Multi-Output - Image 2

DCP-5 - DISCONTINUED

Name: DCP-5 - DISCONTINUED
SKU: DCP-5
Availability: InStock

SEE ALTERNATIVE: DCP-12

$409.28 MSRP

DISCONTINUED | Out of Stock
Recommended Alternative: DCP-12

Compact power distribution device provides eight outputs (5VDC) in a 7-inch x 6-inch chassis, an ideal format to streamline installations that use DC powered devices. It features universal input (100-240VAC, 50/60Hz), C14 power inlet, and 6-ft. detachable power cord (C13 to NEMA 5-15P). Includes mounting brackets.

Add to Favorites

Compare

Features eight outputs (5VDC 11A)
Each output is protected by PTC fuse with auto reset for overload protection.
LED indicates power status (active/inactive).
Detachable voltage output terminals (8) with quick-install screw terminal connectors.
Universal Input: 100-240VAC, 50/60Hz
6 ft. power cord (C13 to NEMA 5-15P plug)
Chassis: 7 in. x 6 in. x 1.625 in.
Brackets for horizontal or vertical installation

Spec Sheet: 2143-DCP5

ETL Listed (UL60065)
Certified U.S. Steel
Assembled in U.S.A. with global components

Power distribution shall be Lowell model DCP-5, which shall feature a 7″ x 6″ x 1.625″ steel chassis with black finish and mounting brackets for vertical or horizontal installation. The unit shall feature 8 voltage outputs, which shall be Euro style output terminals (5VDC, 11A total). Each output shall be protected by an auto-reset PTC fuse. The unit shall feature universal input (100-240VAC 50/60Hz) with C14 power inlet compatible with international standards. It shall include a 6 ft. power cord (C13 to NEMA 5-15) and variable speed fan. The power distribution shall be made in the U.S.A. with global components.

DCP-5 - DISCONTINUED

SEE ALTERNATIVE: DCP-12
