Rackmount power panel, 15A/20A outlets, ASP

PDU with 9 (15/20A) Outlets, Advanced Multi-Stage Surge Suppression

Name: PDU with 9 (15/20A) Outlets, Advanced Multi-Stage Surge Suppression
SKU: ACSPR-2009
Availability: InStock

ACSPR-2009

$943.80 MSRP

The ACSPR Series with 9 outlets (1 front, 8 rear) features Advanced Multi-Stage Surge Protection with TCR (Triple Clamping Redundant) technology to protect electronics against power surges and spikes up to 72,000A when operating at full capacity. LED status indicators serve to alert users if the unit is compromised and in need of repair/replacement. TCR technology includes a 10 year warranty.

Model ACSPR-2009:

Unit Rating: This PDU has a 20A rating and features a 9 ft. power cord with 20A plug (NEMA 5-20P).
Outlets: Receptacles include some 15A (NEMA 5-15R) and 20A (NEMA 5-20R). Some receptacles are controlled by the front activation switch.

Add to Favorites

Compare

Power Rating: 120VAC, 60Hz, 20A
Outlets: 9 (15A/20A) outlets (1 front, 8 rear)
Termination: 9 ft. attached cord with NEMA 5-20P plug
Multi-stage Advanced Surge Suppression protects against power surges up to 72,000A. Includes TCR triple clamping redundant protection with LEDs to monitor status.
On/off Switch: Rocker switch controls 5 rear outlets (1 front and 3 rear outlets are un-switched)
Chassis: 19 in. x 9 in. x 1.75 in. (1U)

Spec Sheet: 1745-ACSPR2009

TAA compliant
BAA compliant
EIA/TIA compliant
ETL Listed in US/Canada (UL60065)
USA-certified steel
Assembled in the USA with global components

The AC power panel shall be Lowell Model ACSPR-2009. It shall be ETL Listed and have a power rating of 120VAC, 60Hz/20A with EMI/RFI filtering and nine outlets (4 un-switched, 5 switched). It shall be housed in a rackmount steel chassis (19 in. x 9 in. x 1.75 in.) finished in black powder epoxy paint. Front activation shall be via a lighted rocker switch. Termination shall be 9 ft. cord with NEMA 5-20P plug. It shall include surge protection to 72,000A.
