ACS-2018-5C-RPCP-HW, 20A POWER STRIP WITH 18 OUTLETS ON 5 CIRCUITS

Power strip, remote power control, 20A, 5 circuit, hardwired, pass-through connections

ACS-2018-5C-RPCP-HW - DISCONTINUED

Name: ACS-2018-5C-RPCP-HW - DISCONTINUED
SKU: ACS-2018-5C-RPCP-HW
Availability: InStock

Out of Stock

$1,148.00 MSRP

DISCONTINUED | Out of Stock

This 120VAC 60Hz 20A power strip with 18 NEMA 5-20R receptacles on five circuits requires a compatible sequencer from the pass-thru series for activation (order separately). Four circuits are controlled by the external sequencer connected via terminal blocks; the other circuit is always on. Termination is via a 6-ft. flexible conduit with pigtail leads tagged for circuit identification. Includes universal mounting brackets.

Add to Favorites

Compare

Power Rating: 120VAC 60Hz 20A
Outlets: 18 NEMA outlets (16 switched, 2 un-switched)
Circuits: 5
RPC: Each switched circuit includes a Remote Power Control terminal with pass-through RJ45 jacks that allow equipment to be turned on/off from a remote location (order compatible sequencer separately)
Surge Suppression: The four switched circuits feature basic surge protection; the un-switched circuit is not protected
Chassis: Steel with black finish, 60 in.
Termination: Hardwired 6-ft. non-metallic flexible conduit with pigtail leads
Universal mounting brackets

Spec Sheet: 2151-ACS20185CRPCPHW

ETL Listed in U.S./Canada (UL60065)
Certified U.S. Steel
Assembled in U.S.A. with global components

The hardwired power strip shall be Lowell model ACS-2018-5C-RPCP-HW with power rating of 120VAC 60Hz 20A. The 60″ x 2″ x 2″ steel chassis with black powder epoxy finish shall include five circuits and nine NEMA 5-20R duplex outlets. One duplex outlet shall be on an unswitched circuit (always on). The other duplex outlets shall be on four switched circuits which shall be activated and deactivated by Lowell power sequencer model SEQ-P4, ordered separately. The power strip shall include surge protection up to 10,000A. It shall also include universal mounting brackets and a six ft. non-metallic flexible conduit with pigtail leads. The unit shall be made in the USA with global components and shall be ETL Listed.
