8A50-TM1670: 8" coaxial driver with 50W transformer

8 inch Coaxial Speaker with 70V 16W Transformer

Name: 8 inch Coaxial Speaker with 70V 16W Transformer
SKU: 8A50-TM1670
Price: 212.00 USD
Availability: InStock

8A50-TM1670

$212.00 MSRP

Model 8A50-TM1670 features an 8-inch 50W coaxial speaker driver, the flagship of the A-Series with greater power handling, lower distortion, and smoother musical sound than standard commercial drivers and is ideally suited to venues where listening is a key part of customer experience. This model includes a mounted 70V 16W transformer. Order grille and enclosure separately.

Add to Favorites

Compare

Driver: 8 in. 50W coaxial with 20 oz. LF magnet coupled with 1.4 in. copper voice coil drives a polypropylene cone with half-roll rubber surround for long cone travel and good edge damping. Post-mounted tweeter (1 in. balanced-drive dome) protected by Ferrofluid and first-order high-pass filter.
Frame: 20-gauge stamped steel with black enamel finish and zinc-plated back-plate
Mounting Bolt Circle: 7.625 in.
Transformer: 70V with taps at 4, 8, 16W
Assembly Frequency Response: 40Hz-17.7kHz (±6dB) and 40Hz-20kHz (±9.2dB)
Assembly Mounting Depth: 6.25 in.
Assembly Dispersion Angle: 90 degrees conical
Assembly Average Sensitivity: 91.8dB

Spec Sheet: 1446-8A50TM1670

Country of Origin (driver): China
Meets or exceeds industry standards

The 8-inch coaxial (50W) driver with mounted transformer shall be Lowell Model No. 8A50-TM1670-S which shall be of the coaxial type having electrically independent high and low frequency transducers. The low frequency section shall have an 8″ diameter polypropylene cone and the high frequency section shall have a tweeter with a 1″ balanced-drive dome. A built-in electrical crossover network shall be employed to accomplish the proper frequency division between the 2 drivers. Crossover frequency shall be at 4000Hz with a first order high-pass filter. Power rating shall be 50 watts RMS. The low frequency voice coil shall have a diameter of 1.4″ and operate in a magnetic field derived from a ferrite (ceramic) magnet with nominal weight of 3.5 lbs. The high frequency voice coil shall have 0.53″ diameter and operate in a magnetic field derived from a ferrite (ceramic) magnet with 2 oz. nominal weight. Voice coil impedance shall be 8 ohms. The driver shall have a round, structurally reinforced stamped 20-ga. steel frame with 8.08″ overall diameter and 8 obround holes equally spaced at 45 degrees on 7.625″ diameter mounting bolt circle. External metal parts shall be finished in black enamel coating or zinc plating to resist rust and corrosion. The mounted transformer shall be 70V with primary taps at 4, 8, and 16W. The assembly shall be capable of producing a uniform audible frequency response over the range of 40Hz-17.4kHz (±6dB) and 40Hz-20kHz (±11.4dB) with a dispersion angle of 90 degrees conical @2000Hz-6dB. Average sensitivity shall measure 90.8dB (SPL at 1W/1M). Overall depth shall not exceed 4.1″.
