50W Mono Volume Control, White | 50LVC-SW - CLOSEOUT

Name: 50W Mono Volume Control, White | 50LVC-SW - CLOSEOUT
SKU: 50LVC-SW
Availability: InStock

Special Pricing - While Supplies Last

$53.00 MSRP

CLOSEOUT | Call 800-325-9660 for Availability
Recommended Alternative: 50LVCDW

Mono autoformer attenuator volume control with rotary dial for use with 25V/70V speaker line features 50W power rating, 3dB per step attenuation (two steps of 6dB each before off) and Phoenix style plug-in screw termination strips. Includes standard one-gang white wall plate.

Add to Favorites

Compare

Power Rating: 50W
Attenuation: 3dB per step (33dB total)
Use With: 25V/70V speaker line
Activation: Rotary dial
Volume Positions: 0-10
Termination: Phoenix-style
Wire Capacity: 14-gauge
Wall Plate: 1-gang standard white plate
Fits standard E.O. box (2.125 in. min. depth)

Spec Sheet: 2229-50LVCSW
Install: 19184-LVC

Assembled in US, China components
ETL Listed (UL60065, UL2043)

The ETL Listed (UL60065, UL2043) volume control shall be Lowell Model 50LVC-SW with 50W power rating and 3dB per step attenuation. It shall include a standard one-gang wall plate with white finish. The device shall mount in an E.O. box with minimum inside dimensions of 1.875 in. x 2.688 in. x 2.125 in. (box not included).

P1X: Surface-mount wall box, 1-gang
